| Item | Description |
| Size | （32±0.1）x（29±0.1）x（2.4±0.2）mm |
| Packing | LCC package, SMD mounting |
| Chipset | Qualcomm MDM9607
|
| Operating voltage | 3.3V - 4.2V, Typical voltage @3.7V |
| Energy-saving current | Standby current < 3mA |
Data
| LTE FDD | DL 150Mbps/UL 50Mbps@20M BW cat4 |
| LTE TDD | DL 130Mbps/UL 35Mbps@20M BW cat4 |
| DC-HSPA+ | DL 42 Mbps/UL 5.76 Mbps |
| UMTS R99 | DL 384 kbps/UL 384 kbps |
| Transmit power | LTE | Class 3 (23dBm±2dB) |
UMTS | Class 3 (24dBm+1/-3dB) |
| Regional version | W-907-CN
| FDD B1/3/5/8 + TDD B38/39/40/41 |
| W-907-EU | FDD B1/3/5/7/8/20/28 + TDD B38/40/41 + WCDMA B1/8 |
| W-907-EC | FDD B1/3/5/7/8/20+ TDD B38/40/41 + WCDMA B1/5/8 |
| W-907-NA | FDD B2/4/5/12/13/25/26 + WCDMA B2/4/5 |
| W-907-J | FDD B1/3/8/18/19/26+ TDD B41 + WCDMA B1/6/8/19 |
| W-907-GL | FDD B1/2/3/4/5/6/7/8/9/12/13/17/18/19/20/25/26/28AB/66+ TDD B38/39/40/41 + WCDMA B1/2/4/5/8 |
| Application Interface | Standard SIM interface | Support 3.0V/1.8V, support hot swap function |
| USB2.0 | •USB2.0 (High-Speed)(Supports slave mode only), data transmission rate up to 480Mbps •For AT commands, data transmission, GNSS NMEA output, software debugging and software upgrades •USB driver: support Windows /Wince/Android /Linux, etc. |
| Hardware reset interface | To reset the module |
| UART serial port | •Main serial port (8 lines): For AT commands and data transmission The maximum baud rate is 921600bps, the default is 115200bps Support RTS and CTS hardware flow control •Debug serial port (2 lines): Used to print module logs |
| PCM interface | •For audio, an external codec chip is required •Supports 8-bit μ-law and 16-bit linear encoding formats •Support short frame mode •Support main mode |
| Power interface | Support 3.3V-4.2V DC power supply |
| Network status indication | Used to indicate the module status. The frequency of the light on indicates different module status. |
| General GPIO interface | •WAKEUP_IN sleep mode control, low level wake up module •AP_READY sleep state detection •W_DISABLE# Flight mode control |
| Satellite Positioning | GPS/BEIDOU/GLONASS Protocol：NMEA |
| Diversity Antenna | Supports LTE diversity antenna |
| AT Command | •Supports standard AT command set (Hayes 3GPP TS 27.007 and 27.005) •Specific AT query AT command set |
| SMS | •Supports Text and PDU modes •Support point-to-point MO and MT •SMS storage: USIM card/ME (default) |
| Virtual Network Card | Support USB virtual network card |
| Temperature range | Normal operating temperature -30℃ to +75℃ Extreme operating temperature -40℃ to +85℃ |
| Storage temperature | -40℃ to + 85℃ |
| Storage humidity | RH5%～RH95% |
| Module function distinction | On the label, m stands for main set, d stands for table set, and g stands for GPS. |
